13.3 Inch Optical Bonding Display Custom Capacitive Industrial Touch Panel Ip65
Product Details:
| Place of Origin: | Guangdong, China |
| Brand Name: | EG |
| Certification: | CE/FCC/ROHS/ISO9001/ISO14001 |
| Model Number: | EG-13.3-A-1609V1 |
Payment & Shipping Terms:
| Minimum Order Quantity: | 2 sets |
|---|---|
| Price: | $28.00/sets 2-499 sets |
| Packaging Details: | Inner packaging: packing with bubble bags and filling with foam plastic materials; <br>Outer packaging: packing with serial size of carton or wooden box.<br><br>24'' Capacitive multi touch panel with USB port support multi points |
| Supply Ability: | 10000 Piece/Pieces per Week |
|
Detail Information |
|||
| Type: | COB | Display Size: | 13.3 [16:9] |
|---|---|---|---|
| Aspect Ratio: | 16:9 | Touch Points: | 10 Points |
| Printing: | Black | Port: | Guangzhou Port/ Shenzhen Port,China |
| High Light: | 13.3 inch optical bonding display,capacitive touch optical bonding display,13.3 inch optical bonding touch screen |
||
Product Description
15.6 Inch Custom Capacitive Industrial Touch Panel Waterproof IP65
| Size | 15.6 inch |
| Structure | G+G |
| Touch controller | EETI / ILITEK |
| Surface hardness | >6H |
| Outline Dimension | 207.80(W)*324.10(L)±0.2 mm |
| View Area | 164.24(W)*292.76(L)±0.2 mm |
| Active Area | 165.24(W)*293.76(L)±0.2 mm |
| Sensor glass Thickness | 0.7±0.05 mm |
| Cover lens Thickness | 2.0±0.2 mm |
| Total Thickness | 2.9±0.2 mm |
| Chamfer | R5 mm |
| Sensor Proces | Print Process(ITO Pattern) + laser line(Ag) |
| Transmittance | >85% |
| Touch point | 10 points |
| Relative Humidity | 95% at 60℃, RH Non-condensing |
| Interface Type | USB,RS232,I2C |
| Warranty | 3 years |
Lens's features |
Sensor features |
| Shape: Standard/Customization Color:Silkprinting,logo Glass material:Glass, PMMA Treatment:AR/AF/AG/Anti-UV Thickness:1.1-12mm |
Material:Glass,film FPC:Shape design optional IC:EETI/ILITEK Interface:12C/USB/RS232 |
- How can we guarantee quality?
All products must pass 5 times QC inspection with 100% appearance& Function test on each piece.
- Which operating systems does is support?
Our products support Windows,Android,Mac,Linux and Chrome.
- What are the advantages of our products?
High precision,response quickly,good quality control,excellent after-service.
- What is included in your products?
Touch panel+LCD display+Air bonding/Optical bonding+Controller board+USB Cable.(AD borad and display cables are optional)
- Do you support sample testing?
Yes,We can provide standard model in stock or customized sample in 3-7 days for testing purpose.
