19 Inch Optical Bonding Display Anti Fingerprint Waterproof For Outdoor
Product Details:
| Place of Origin: | Guangdong, China |
| Brand Name: | EG |
| Certification: | CE/FCC/ROHS/ISO9001/ISO14001 |
| Model Number: | EG-19-A-1610V1 |
Payment & Shipping Terms:
| Minimum Order Quantity: | 2 units |
|---|---|
| Price: | $135/units 2-499 units |
| Packaging Details: | Standard Packaging:Wooden box with foam |
| Supply Ability: | 100000 Piece/Pieces per Month |
|
Detail Information |
|||
| Touch Panel P/N: | EG-19-A-1610V1 | Display Size: | TM101JDHG30_V2.0 |
|---|---|---|---|
| Contrast Ratio: | 1000Typ. | Support Color: | 262K/16.7M |
| Interface: | USB, RS232, I2C | Operating System: | WindowsXP/7/8,10 Android,Linux,Mac |
| Luminance, White: | 250 Typ. Cd/m2 | Touch Points: | Multi Touch |
| Color: | Black,Silver | ||
| High Light: | 19 Inch Optical Bonding Display,Optical Bonding Display Anti Fingerprint,Outdoor display optical bonding |
||
Product Description
19 Inch Optical Bonding Display Anti-Fingerprint Coating Impact Resistance Waterproof Design For Outdoor
| Touch Panel P/N | EG-19-A-1610V1 |
| Display P/N | M190PW01 V8 |
| Screen Diagonal | 19/16:10 |
| Cover Outline Dimension | 444.4*291.3 mm |
| Touch Panel View Area | 410.4*256.5 mm |
| Touch Panel Active Area | 411.4*157.5 mm |
| Display Outline Dimension | 428*278 mm |
| Display Active Area | 408.24*255.16 mm |
| Display Thickness | 14.2 mm |
| View angle | 89/89/89/89, Full view angle |
| Impact resistance | ≥IK07 |
| Luminance, white | 250cd/m2 |
| Operation Conditions | 10%-90%RH |
| Touch Response Time | ≤25 ms |
| Pixels H×V | 1920(x3) x 1080 |
| Pixel Pitch |
0.15285x 0.15285 mm |
| Shape:Standard/Customization | Material:Glass,Film | Optical Bonding |
| Color:Silkprinting,logo | FPC:Shape Design Optional | Air Bonding |
| Glass material:Glass,PMMA | IC:EETI/ILITEK | LCD:LED,OLED,TFT,IPS |
| Treatment:AR/AF/AG/Anti-UV | Interface:12C/USB/RS232 | |
| Thickness:1.1-12mm |
- How can we guarantee quality?
All products must pass 5 times QC inspection with 100% appearance& Function test on each piece.
- Which operating systems does is support?
Our products support Windows,Android,Mac,Linux and Chrome.
- What are the advantages of our products?
High precision,response quickly,good quality control,excellent after-service.
- What is included in your products?
Touch panel+LCD display+Air bonding/Optical bonding+Controller board+USB Cable.(AD borad and display cables are optional)
- Do you support sample testing?
Yes,We can provide standard model in stock or customized sample in 3-7 days for testing purpose.
