23.8 Inch LCD Touch Display Panel Air Bonding 10 Points For Gaming
Product Details:
| Place of Origin: | Guangdong, China |
| Brand Name: | EG |
| Certification: | CE/FCC/ROHS/ISO9001/ISO14001 |
Payment & Shipping Terms:
| Minimum Order Quantity: | 2 pieces |
|---|---|
| Price: | $240.00/pieces 2-499 pieces |
| Packaging Details: | Inner packaging: packing with bubble bags and filling with foam plastic materials; Outer packaging: packing with serial size of carton or wooden box. |
| Supply Ability: | 100000 Piece/Pieces per Month |
|
Detail Information |
|||
| Type: | Capacitive | Display Size: | 23.8 Inch |
|---|---|---|---|
| Products Status: | Stock | Touch Points: | 10 Points |
| Support Color: | 16.7M Colors (RGB 8-bit ) | Outline Dimension: | 567.44(W)*336.86(L) ±0.2mm |
| Active Area: | 528.44(W)*297.86(L)±0.2mm | Pixels H×V: | 1920(x3) X 1080 Pixel |
| Transmittance: | ＞85% | Interface: | USB/RS232/IIC |
| TFT Quality: | Original New | Touch Controller: | EETI ILITEK |
| Port: | Shenzhen Port/Guangzhou Port, China | ||
| High Light: | 23.8 Inch Touch Display Panel,Touch Display Panel Air Bonding,Gaming lcd touch panel |
||
Product Description
23.8 Inch Touch Display Panel With Pcap IPS TFT LCD Display Panel Air Bonding For Gaming
| Touch Panel P/N | EG-23.8-A-1609V1 |
| Display P/N | G238HAN01.1 |
| Screen Diagonal | 23.8/16:9 |
| Cover Outline Dimension | 567.44*336.86mm |
| Touch Panel View Area | 527.44*296.86mm |
| Touch Panel Active Area | 528.44*297.86mm |
| Touch Panel Thickness | 2.9mm |
| Display Outline Dimension | 543*317.4mm |
| Display Active Area | 527.04*296.46mm |
| Display Thickness | 11.15mm |
| Total Thickness | 15.05mm |
| Impact resistance | ≥IK07 |
| Shape:Standard/Customization | Material:Glass,Film | Optical Bonding |
| Color:Silkprinting,logo | FPC:Shape Design Optional | Air Bonding |
| Glass material:Glass,PMMA | IC:EETI/ILITEK | LCD:LED,OLED,TFT,IPS |
| Treatment:AR/AF/AG/Anti-UV | Interface:12C/USB/RS232 | |
| Thickness:1.1-12mm |
- How can we guarantee quality?
All products must pass 5 times QC inspection with 100% appearance& Function test on each piece.
- Which operating systems does is support?
Our products support Windows,Android,Mac,Linux and Chrome.
- What are the advantages of our products?
High precision,response quickly,good quality control,excellent after-service.
- What is included in your products?
Touch panel+LCD display+Air bonding/Optical bonding+Controller board+USB Cable.(AD borad and display cables are optional)
- Do you support sample testing?
Yes,We can provide standard model in stock or customized sample in 3-7 days for testing purpose.
